Optical Fiber Circulator 980nm/850nm Fiber Optical Circulator
polarization insensitive optical circulator utilizes proprietary designs and metal bonding micro optics packaging. It provides low insertion loss, broad band high isolation, low PDL, excellent temperature stability and optical path epoxy free. It can be used for wavelength add/drop, dispersion compensation and EDFA application.
◇Features:
Low Insertion Loss
High extinction ratio
High isolation
Excellent stability and reliability
◇ Application:
Optical Amplifier
CATV Systems & Fiberoptic Sensors
Fiber lasers
Dispersion Compensation
| Parameter | Specification | ||
| Operating Wavelength (nm) | 980±20 | 850±20 | |
| Isolation (dB) | Typical | 25 | |
| Minimum | 20 | ||
| Insertion Loss (dB) | Typica | 1.3 | |
| Maximum | 1.8 | ||
| Cross Talk(dB) | 45 | ||
| Return Loss (dB) | 50 | ||
| Polarization Dependent Loss (dB) | 0.2 | ||
| Opterating Temperature(℃) | 0~+50 | ||
| Storage Temperaturel(℃) | -40~+85 | ||
| Package dimension(mm) | L62.6×W28×H27 | ||
| Power Handling(mW) | 300~10Wor Specify | ||
| 1,Specifications may change without notice. | |||
| 2,Above specification are for device without connector. | |||
| PIOC | Connector | Wavelength | Grade | Fiber type | Pigtail length |
| 11-ST 21-FC/PO 31-SC/PO 41-LC/PO 51-MU/PC 00-None XX-Others | 98-980 nm 85-850 nm | P-P Grade | 2-50/125um 3-62.5/125um x-Others | 050-50cm 100-100cm 150-150cm 200-200cm 000- Modulized xxx-Others |
